Product Details & Specifications
- Brand: SGM
- Power supply voltage: 1.65V-5.5V
- Specifications and models: SGM7SZ04XN5G/TR
- Specifications and models: SGM7SZ04YN5G/TR
SGM7SZ04 原装反相器IC SGM7SZ04XN5G/TR 丝印SF4NJ SGM7SZ04YN5G
GENERAL DESCRIPTIONThe :
SGM7SZ04 is a single inverter with the advancedCMOS technology. The supply voltage pin of thisdevice accepts any voltage from 1.65V to 5.5V. Theinput can tolerate the maximum of 6V, regardless of thesupply voltage range. When VCC is 0V, the input andoutput are in the high-impedance state.This device can achieve ultra-high speed operation withhigh output drive, meanwhile, the low static powerdissipation is maintained over the wide supply voltageoperating range.The SGM7SZ04 is available in Green UTDFN-1.45×1-6L,SC70-5 and SOT-23-5 packages. It operates over anambient temperature range of -40℃ to +125℃.
FEATURES:
● Wide Supply Voltage Range: 1.65V to 5.5V ● Inputs Over-Voltage Tolerance Makes 5V to 3V Translation Available ● +24mA/-24mA Output Current at VCC = 3V ● Ultra-High Speed: tPD of 4.2ns (TYP) into 50pF at VCC = 3.3V ● Support LCX Performance at VCC = 3.3V ● Power Down High-Impedance Input/Output ● -40℃ to +125℃ Operating Temperature Range ● Available in Green UTDFN-1.45×1-6L, SC70-5 and SOT-23-5 Packages
