Name: Lm2596s Dc-dc Step-down Power Module Buck 3a Adjustable Step-down...
Brand: C2G Mall
Availability: InStock

Brand: Junteng Microelectronics
Power supply voltage: See details
Output current: Default item
Specification model: Adjustable output (assembled for shipping, fragile, no warranty for damage, purchase with caution) - Adjustable output (assembled for shipping, fragile, no warranty for damage, purchase with caution) - Electronic products
Specification model: Adjustable output (individually packaged) - Adjustable output (individually packaged) - Electronics - Bagged
Specification model: Fixed 3.3v-Fixed 3.3v-Electronic Products-Packaged
Specification model: Fixed 5v-Fixed 5v-Electronic Products-Packaged in Bags
Specification model: Fixed 12v-Fixed 12v-Electronic Products-Packaged in Bags
The way of packing: Bagged
The way of packing: Jigsaw puzzle
Packaging specifications: Fixed 12v
Packaging specifications: Fixed 5v
Packaging specifications: Fixed 3.3v
Packaging specifications: Adjustable output (individually packaged)
Packaging specifications: Adjustable output (packaged for easy shipping, fragile, no warranty for damage, purchase with caution)
Application field: Electronic products

接线端口：

IN+ 输入正极 IN-输入负极!

OUT+输出正极 OUT-输出负极

LM2596S DC-DC 降压电源模块BUCK 3A可调降压模块稳压超LM2576

工业级加料不加价

低纹波大电流高效率90%

实力厂家新品！

综合改进性能！

量大更优惠！

密集的过孔，散热能力强！

在输入与输出端分别增加X7R高Q高频旁路电容，电磁兼容性能超强！

输入电压范围：直流3.2V 至 46V 建议在40V内使用！ (输入的电压必须比要输出的电压高1.5V以上。不能升压)

输出电压范围：直流 1.25V至 35V 电压连续可调，高效率(最大92%)最大输出电流为3A。

实测12V输入，5V输出电流1A时的负载调整率低于1%

注：此为降压模块，输入电压必需比输出电压高。

输出2A以下可以长时间不用加散热片输出电流大于2.5A（或输出功率大于10W）长时间工作请加散热片。
